HBSig

HyperBEAM / AO-Core requires complex encoding and signing involving multiple codecs and HTTP Message Signatures. However, it is not 100% compatible with the standard http-message-signatures libraries, and aoconnect only provides basic encoding for AOS messages.

hbsig handles encoding of arbitrarily complex objects, which works on HyperBEAM. It is built by emulating the HyperBEAM codec devices as well as creating workaround encoding strategies using a custom device for extensive tests with LLMs.

Installation

hbsig is a standalone package providing utility methods for HyperBEAM codecs, signatures, encoding and hash algorithms.

yarn add hbsig

Sign Message

createSigner

import { createSigner } from "hbsig"

const hyperbeam_url = "http://localhost:10001"
const sign = createSigner(jwk, hyperbeam_url)

Sign and Send Message

hbsig can encode and sign almost any complex objects combining layers of HyperBEAM codecs and http-message-signatures. While there are a few edge cases where HyperBEAM's decoder has limitations, hbsig intelligently provides workarounds for many of these scenarios. The encoding strategies were refined through extensive battle-testing with LLMs.

import { send } from "hbsig"

const msg = { str: "abc", num: 123, bin: Buffer.from([1,2,3]) }
const signed = await sign({ path: "/~hbsig@1.0/msg2", ...msg })
const { out } = await send(signed)

Exclude @path

@path is automatically included in the signed components. To exclude @path, set path=false in the 2nd argument. There are some cases you want to exclude @path due to HyperBEAM's non-standard handing of the path field. HyperBEAM strips off the leading / from path, and also removes @ from the field name in the signed body, which might not be compatible with the Http Message Signatures standard, and invalidates signatures in some scenarios.

const msg = await sign(
  { path: "/~hbsig@1.0/msg2", key: "value" },
  { path: false }
)

Verify Message

You can verify signed messages while decoding signature-input.

import { verify } from "hbsig"

const {
  valid, // should be true
  verified,
  signatureName,
  keyId,
  algorithm,
  decodedSignatureInput : { components, params: { alg, keyid, tag }, raw }
} = await verify(signed)

Commitments

You can sign a message and create commitments with the signature.

import { commit } from "hbsig"
const committed = await commit({path, ...msg}, { signer: sign })

Commit IDs

A commitment needs to include two IDs, which are

• sha256 hash of the signature
• hmac-sha256 hash of the signed components

You can explicitly get these IDs from a signed message.

import { rsaid, hmacid } from "hbsig"

const hmac_id = hmacid(signed.headers)
const rsa_id = rsaid(signed.headers)

Message ID

You can calculate the ID from committed message.

import { id } from "hbsig"

const msg_id = id(committed)

Hashpath

You can calculate the next hashpath from the current hashpath and a new message.

import { hashpath } from "hbsig"

const next_hashpath = hashpath(current_hashpath, committed)

base

A hashpath consists of the hash of the current hashpath and the new message ID joined by /. You can independently calculate the base hash with base.

import { base, id } from "hbsig"
const next_hashpath = `${base(current_hashpath)}/${id(committed)}`

Utilities

toAddr

Synchronously calculate Arweave address from a public key. arweave.js provides only asynchronous method for this. You can extract a public key from jwk.n as well as verify(signed), which gives you keyId from signature-input.

import { toAddr } from "hbsig"
const address = toAddr(jwk.n) // toAddr(jwk) works too

Codecs

hbsig internally handles many different representations of the same object using multiple codecs from HyperBEAM (flat structured httpsig) and 2 added codecs to achieve seamless data exchange between JS and Erlang (erljson erlstr).

hbsig@1.0 Device

hbsig comes with an accompanying device (hbsig@1.0) on HyperBEAM to validate various encoding strategies.

git clone https://github.com/weavedb/wao.git && cd wao
git submodule update --init --recursive

• json_to_erl/3 : convert stringified JSON to an Erlang object
• to_erl/1 : convert stringified JSON in body to an Erlang object
• to_str/1 : convert an Erlang object to ErlStr
• structured_from/3 : expose structured@1.0:from
• structured_to/3 : expose structured@1.0:to
• httpsig_from/3 : expose httpsig@1.0:from
• httpsig_to/3 : expose httpsig@1.0:to
• flat_from/3: expose flat@1.0:from
• flat_to/3: expose flat@1.0:to
• msg2/3 : return Msg2 as ErlStr so we can check the decoded message

ErlJSON

JSON and erlang objects have different types such as null, boolean, and atom. ErlJSON normalized JSON objects to Erlang compatible structures.

import { normalize, erl_json_from, erl_json_to } from "hbsig"

ErlStr

Erlang doesn't differentiate between strings and buffers, and the built-in format method loses precision when converting binary data containing non-standard characters. To address this, ErlStr maintains both binary and stringified formats for accurate Erlang-to-JSON conversion.

import { erl_str_from, erl_str_to } from "hbsig"

ErlJSON and ErlStr enable seamless conversions between JSON and Erlang objects, allowing precise encoding tests across both environments.

flat

import { flat_from, flat_to } from "hbsig"

structured

import { structured_from, structured_to } from "hbsig"

httpsig

import { httpsig_from, httpsig_to } from "hbsig"

Example Test

You can find comprehensive encoding tests here.

import { structured_from, structured_to } from "../src/structured.js"
import { normalize, erl_json_to } from "../src/erl_json.js"
import { httpsig_from, httpsig_to } from "../src/httpsig.js"

describe(desc, function () {
  let hbeam, sign
  before(async () => {
    hbeam = await new HyperBEAM({ reset: true }).ready()
    sign = createSigner(hbeam.jwk, hbeam.url)
  })
  after(async () => hbeam.kill())
  it("should validate", async ()=>{
    const msg = { str: "abc", num: 123, bin: Buffer.from([1, 2, 3]) }
	const structured = structured_from(normalize(msg))
    const json = erl_json_to(structured)
    const signed = await sign({
	  path: "/~hbsig@1.0/httpsig_to",
	  body: JSON.stringify(json)
	})
    const { out } = await send(signed)
    const input = httpsig_to(normalize(structured))
    const output = erl_str_from(out)
    const expected = normalize(input, true)
    const output_b = erl_str_from(out, true) // true for binary format
    assert.deepEqual(expected, output_b) // compare in binary format
  })
})

To run all tests, you need to clone wao branch of HyperBEAM, compile it, add .wallet.json, and set CWD in .env.hyperbeam.

yarn test-all
