WAO Devnet Alpha

WAO Devnet

What is WAO Devnet

AO is a decentralized compute network built on Arweave. In production, it runs as five independent unit types — each operated by different parties across the network:

Unit	Role
AR	Arweave gateway — stores transactions and provides GraphQL queries
SU	Scheduler — orders messages into a deterministic sequence per process
MU	Messenger — accepts signed messages, forwards them to the scheduler, and triggers computation
CU	Compute — evaluates process state by replaying messages through WASM modules
BD	Bundler — batches transactions into bundles and posts them to Arweave

WAO Devnet collapses all five units into a single Cloudflare Worker. It runs the full AO protocol — scheduling, computation, storage, GraphQL — and your code talks to the same APIs. Developing against the live network means slow round-trips, no local visibility, and costly on-chain mistakes. Devnet gives you the real protocol with none of that.

Not Permanent

AO's mainnet and testnet both write to Arweave — every transaction is permanently stored on-chain. WAO Devnet does not write to Arweave. The AR unit emulates the Arweave gateway API, but all state lives on Cloudflare infrastructure. There are no block confirmations, no storage costs, and no permanent footprint.

To reset your local devnet, delete the .wrangler/ directory and restart:

rm -rf .wrangler
npx wrangler dev --port 8788

For custom storage paths, delete whichever --persist-to directory you specified.

Preloaded WASM Modules

Cloudflare Workers cannot dynamically load WASM at runtime — all modules must be bundled at build time. Because of this limitation, devnet ships with AOS WASM modules preloaded into the Worker bundle:

Module ID	Binary	Format
`ISShJH1ij-hPPt9St5UFFr_8Ys3Kj5cyg7zrMGt7H9s`	AOS 2.0.6	wasm64
`JArYBF-D8q2OmZ4Mok00sD2Y_6SYEQ7Hjx-6VZ_jl3g`	AOS 2.0.3	wasm64
`Do_Uc2Sju_ffp6Ev0AnLVdPtot15rvMjP-a9VVaA5fM`	AOS 2.0.1	wasm64
`WASM32-D8q2OmZ4Mok00sD2Y_6SYEQ7Hjx-6VZ_jl3g`	AOS 2.0.4	wasm32
`ghSkge2sIUD_F00ym5sEimC63BDBuBrq4b5OcwxOjiw`	SQLite	wasm64

Network Identity: `ao.DN.1`

Every AO network has an identity tag. Mainnet uses ao.N.1. WAO Devnet identifies itself as ao.DN.1 (DevNet 1). This tag appears in the network info returned by GET /ar:

{ "network": "ao.DN.1", "height": 42 }

You can deploy your own devnet with a custom identity tag (e.g. ao.MYAPP.1) — the last segment is the version number.

Architecture

┌─────────────────────────────────────────────┐
│             Cloudflare Worker               │
│                                             │
│   Hono Router                               │
│   ├── /ar/*    → Arweave Gateway (AR)       │
│   ├── /bd/*    → Bundler (BD)               │
│   ├── /mu/*    → Messenger Unit (MU)        │
│   ├── /su/*    → Scheduler Unit (SU)        │
│   ├── /cu/*    → Compute Unit (CU)          │
│   ├── /ws      → WebSocket (live updates)   │
│   └── /        → WAO Scan (explorer UI)     │
│                                             │
│   ┌─────────────────────────────────────┐   │
│   │       DevnetDO  (Singleton)         │   │
│   │                                     │   │
│   │   WAO Adaptor                       │   │
│   │   ├── Arweave emulation (ArMem)     │   │
│   │   ├── GraphQL engine                │   │
│   │   ├── AOS WASM execution (wasm64)   │   │
│   │   └── Transaction & block storage   │   │
│   │                                     │   │
│   │   WebSocket broadcaster             │   │
│   └─────────────────────────────────────┘   │
│                                             │
│   Storage: Durable Objects · D1 · R2 · KV   │
└─────────────────────────────────────────────┘

The Hono router maps requests to the correct unit by path prefix and forwards them to the DevnetDO singleton. The Durable Object runs the WAO Adaptor and routes requests through it. POST mutations broadcast over WebSocket so WAO Scan updates in real time.

Why Cloudflare

AO units need to handle HTTP requests, execute WASM, manage persistent state, and coordinate in real time. Cloudflare's edge platform provides all of this — no servers to manage, no infrastructure to provision, and a generous free tier.

Service	Role in Devnet
Workers	Runs the Hono router and all AO unit logic. V8 isolates with sub-5ms cold starts.
Durable Objects	The `DevnetDO` singleton — strong consistency, in-memory caching, and WebSocket support in one actor.
D1	SQLite for transaction metadata and GraphQL queries. Indexed lookups by owner, recipient, tags, and block height.
R2	Object storage for WASM modules, transaction data, and process memory snapshots. Zero egress fees.
KV	Global key-value cache for module lookups and address mappings.

All five services are accessible within a single Worker — a message that enters through the MU, gets scheduled by the SU, evaluated by the CU, and stored by the AR never leaves the edge. The entire pipeline runs in-process. And everything above fits within Cloudflare's free tier — Workers (100k requests/day), D1 (5 GB), R2 (10 GB), KV (100k reads/day), Durable Objects (included with Workers Paid, or minimal cost). A full devnet deployment costs nothing for typical development workloads.

Locally, wrangler dev emulates all of these services on your machine. The same code runs in both environments.

Scalability

Each devnet is a self-contained Worker deployment. You can run as many as you need:

Per-developer — each team member deploys their own isolated devnet
Per-environment — separate devnets for development, staging, CI, and demos
Per-project — different applications get different networks with different state

name = "wao-devnet-alice"   # personal devnet
name = "wao-devnet-ci"      # CI pipeline
name = "wao-devnet-demo"    # demo environment

You can also split units across Workers using the UNITS configuration — run a compute-heavy CU on a dedicated Worker while the MU/SU/AR share another. See Running a Devnet Node for details.

Next Steps

Running a Devnet Node — Run locally or deploy to Cloudflare
WAO Scan — Built-in block explorer
API Endpoints — Full reference for all unit endpoints
